Description

MECHANICAL PROPERTIES

• Cells 6 x 10 Cell vendor LG
• Cell type Monocrystalline Cell dimensions156 x 156 mm2 / 6 x 6 in2
• # of busbar 3 Dimensions (L x W x H)1632 x 986 x 42 mm / 64.25 x 38.82 x 1.65 in
• Maximum load (Pa)113 psf (5400 Pa) Weight 19 kg / 41.89 lb
• Connector typeTyco connector IP 67Junction box IP 65 with 3 bypass diodes
• Length of cables 2 x 1000 mm / 2 x 39.37 in * Under the IEC standards/ NEC 2008
compliant

ELECTRICAL PROPERTIES (STC*)

• Maximum power at STC (Pmax) 245 MPP voltage (Vmpp) 29.8
• MPP current (Impp) 8.23 Open circuit voltage (Voc) 37.0
• Short circuit current (Isc) 8.67 Module efficiency (%) 15.2
• Operating temperature (°C) -40 ~ +90 Maximum system voltage (V)600
• Maximum series fuse rating (A) 20 Power tolerance (%) 0 ~ +3
• *Power at STC (Standard Test Condition): Irradiance 1000 W/m2, module
temperature 25 °C, AM 1.5/ The nameplate power output is measured and
determined by LG Electronics at its sole and absolute discretion.

ELECTRICAL PROPERTIES (NOCT*)

• Maximum power (W)172 Maximum power voltage (V) 27.25
• Maximum power current (A) 6.31Open circuit voltage (Voc) 34.45
• Short circuit current (Isc) 6.70 Efficiency reduction (from 1000 W/m2 to 200 W/m2) <
4.5 %
• *Power at NOCT (Nominal Operating Cell Temperature): Irradiance 800 W/m2,
ambient temperature 20 °C,wind speed 1 m/s
